The 4 Channel Car DVR Recorder Parking Assistant is a must-have device for vehicle owners looking for added security and convenience. With four channels, it can simultaneously record footage from all angles around your car, providing valuable evidence in case of accidents or theft. It also features parking assistance functionality to help you park with ease.
Support power to 4 camera with trigger function.
Automatic mode description: (digital on behalf of the corresponding camera channel number, channel number is not displayed)
(1) When the access to four cameras, the car starts after the camera work, automatically display four images at the same time [H-type], 5 seconds after the delay automatically shut down.
(2) When the access to three cameras, the car starts after the camera work, automatically display three images at the same time [product type], 5 seconds after the delay automatically shut down.
(3) When access to two cameras, the car starts after the camera work, automatically display two images at the same time [left and right / up and down segmentation], 5 seconds after the delay automatically shut down.
(4) Front view [Channel 1] Trigger boot, display front view large screen, trigger exit delay 3 seconds after the automatic closure.
(5) Front view or reversing trigger After turning on, the left turn button triggers the display to turn left big screen 【Channel 2】, and the image is restored to 3 seconds after the display.
(6) Front view or reversing trigger After turning on, the right turn light trigger display right turn big screen 【Channel 4】, display 3 seconds to return to the automatic segmentation image screen.
(7) reversing [channel 3] trigger boot, hanging upshift display reversing large screen, out of hanging back and forth delay display automatically closed after 3 seconds,
Manual mode description:
1. Press the upper left corner to boot, display the automatic split image screen, auto off mode failure, press again to turn off, automatic mode takes effect.
2. Press the button to extend the line to boot, short press to switch the screen mode. (Long press> 1 second, short press <1 second)
Host box using high integration technology, four cameras from the main box of centralized power supply, which greatly reduces the installation of the wiring of the cumbersome, the other four camera images collected by the host after conversion by a video line and navigation DVD "AV" Port connection
This device can recorder when the card stop with lower Low power, no power consumption
Please pay attention, this item is not included the camera, if you want the camera, Please contact us, we will recommend you and give you a best price for the full set. Thank you for your attention.
