Contact Material: Brass
-
Termination Type: Screw
-
Power Mode: Uncharged
-
Battery Properties: Without Battery
Model: DC022B(3.5*1.3)
Type of socket: DC socket
Plug in life: 10000 times
Electroplating process: Tin plating
Rated voltage: 50V
3C Rated voltage range: below 50V
Thread: M8.0 * 0.5
Rated current: 1A
Shell material: ABS
Standard type: National standard
Product series: DC socket
Whether for foreign trade: Yes
Plug in force: 3-20N
Product Introduction
A DC socket is a type of socket that is compatible with a dedicated power supply for computer monitors. It consists of a horizontal socket, a vertical socket, an insulated base, fork shaped contact springs, and directional key slots. The two fork shaped contact springs are positioned at the center of the base and arranged vertically and horizontally without being connected to each other. One end of the fork shaped contact spring is a wiring port, exposed on the top surface of the base cylinder, for connecting input power cords or cables. The other end of the fork shaped contact spring is composed of two elastic arms interconnected by the base, set in the insulated base socket in the direction of DC plug insertion, for supplying the computer display to work normally.
