Maxspeedingrods Billet TD05 20G Turbo for Subaru Impreza WRX STI EJ20 EJ25 Max Rated - 420HP, Water and Oil Cooled (10006776)

Upgrade your Subaru Impreza WRX/STI with the TD05 20G Turbo for a boost in performance up to 420HP. This turbo is designed for EJ20/EJ25 engines, delivering maximum power and efficiency.

It's a upgraded Turbo for advanced drivers. Our TD05 20G Turbo customizes a unique specification that replaces the TD04 for a TD05H turbine wheel. Furthermore, MXR also enlarges the turbine housing area to 7 square cm to improve the exhaust efficiency. so expect to gain more power than stock turbo.

Molybdenum silicon turbine casing for high temperature environment, reliable, stable and durable

The K419 alloy turbine wheel under high temperature converts exhaust gases into kinetic energy and runs smoothly

Forged billet aluminum CNC machined compressor wheel runs efficiently and consumes less fuel

Abrasion and heat-resistant high-speed steel oil seal ring, effectively preventing oil leakage

Application

TD05 20G Upgraded Turbo For Subaru IMPREZA WRX / STI EJ20 EJ25 engine 2002 - 2006 *Notice: All WRX Wagon engines and automatic sedan engines came with a TD04,all manual WRX sedans including STI versions had a TD05 model. If your original turbo is TD04 model, some modification(connections, bolts, fixed screws etc.) is required.

Specification

Exhaust Outlet Flange:5-Bolt Flange Exhaust Intlet Flange:3-Bolts Flange Turbine Side: Turbine Trim: 76.4 Turbine Housing: 7cm⊃2; Turbine Inducer Diameter:56mm Turbine Exducer Diameter: 48.96mm Compressor Side: Compressor Trim: 59.8 Compressor Inducer Diameter: 52.6mm Compressor Exducer Diameter:67.9mm Compressor Housing Inlet OD: 57.8mm Oil Feed: M10*1.5 Oil Drain: 2*M6*1.0 Water In/Out: M14*1.5 Turbine housing: 7cm⊃2; Compressor housing inlet OD: 57.8mm,ID:53.62mm Compressor housing outlet OD: 51.2mm,ID:41.2mm Bearing: Wet Float/Journal Bearing Cooling Type: Water + Oil cooled Wastegate：With Wastegate Turbo Model: TD05 20G Thrust Bearing:270 degree Hosepower: Up to 420 HP Turbo Type: Individual Universal Fitment: No Finish: Matte Accessories: You will get exactly as shown as picture above Condition: 100% Brand New Package Size:30x 28x 24 cm Package Weight: 7650g

Package Contents

1xTurbocharger 2xFlange gaskets 2xOil/Water port gaskets 1xManual 1xBrochure 1xSticker

Feature

*Product Material 1. Turbine housing ：Silicon-Molybdenum - temperature resistant up to 850℃ 2. Steel Turbine Wheel：K419 alloy - high oxidation stability and resistance up to 1000℃ 3. Compressor housing：ZL104 aluminum with lightweight 4. Billet compressor wheel: forged full-machined billet aluminum compressor wheels with a larger horsepower range and better boost response *Product Performance 1. OEM fitment turbo with upgraded material and performance 2. Excellent high temperature resistance,high efficiency and durability 3. Rich experience in turbo production and own factory 4. High-Speed oil seal ring and Precision clearance * Technology Advantage: 1. 100% balancing Test by TURBOTECHNICS VSR3 2. Advanced Actuator Tester/Programmer
