Specifications:
| Plug Type |
EU Plug |
| Charging voltage |
15.2V (light green when no load) |
| Charging voltage range, the highest voltage is not higher than 25.5V, the voltage in the constant current phase is random- but not higher than 25.5V |
| Output current |
2A (constant current charging, the indicator light is red) |
| Conversion current |
200mA-300mA(after full conversion, the indicator light is green) |
| Ripple and noise (Note 3) |
<100mVp-p (constant voltage) |
| Line adjustment rate (Note 4) |
±0.8% |
| Load regulation rate (Note 5) |
±1% |
| DC output power |
50.4W |
| Efficiency |
>85% (maximum output voltage, full load) |
| DC voltage adjustable range |
0-25.2V |
| Input voltage range |
100 ~ 240VAC; 47 ~ 63Hz; 140-350VDC |
| Input current |
0.03A/230V |
| Inrush current |
cold start current 2A/230V |
| Leakage current |
<3.5mA |
| Overload protection |
105%~150%, Type: FOLDBACK current limit output Reset: automatic recovery |
| Temperature coefficient |
±0.03% °C (0 ~ 50 °C) OUTPUT |
| Start- rise- hold time |
200ms, 50ms, 30ms |
| Shock resistance |
10 ~ 500Hz, 2G 10min. / 1 cycle duration 60 minutes each axis |
| Pressure resistance, input--output |
1.5KVAC |
| Isolation resistance, input and output |
10M Ohms |
| Working temperature, humidity |
-10 ° C ~ +50 ° C- 20% ~ 90% RH |
| Storage temperature, temperature |
-10 ° C ~ +60 ° C- 20% ~ 90% RH |
| Dimensions |
115 × 48 × 30mm |
| Weight |
169G |
Features:
- It has: constant voltage, constant current, over voltage, over current protection function;
- Indicator light conversion;
- Automatic recovery and other functions.
Package Contents:
1 x Lithium battery pack charger
