with IP65 Waterproof 22-50VDC Input to 220VAC Pure Sine Wave Inverter
The 600W MPPT Micro Grid Tie Solar Pure Sine Inverter is designed to convert solar energy into usable electricity for residential or commercial use. It features Maximum Power Point Tracking technology for efficient energy conversion.
-
Model Number: WVC-600W
-
Input Voltage: 22-50V
-
Output Voltage: 110V-230V
-
Output Current: 25A
-
Output Frequency: 57-62.5 Hz
-
Output Type: Single
-
Size: 34x25x12 cm
-
Type: DC/AC Inverters
-
Weight: 2.45 kg
-
Product name: Grid Tie Inverter
-
Application: Solar Power System Home
-
Ambient temperature: -40~+60 ℃
-
Operating voltage range: 17-50V
-
Min/Max start voltage: 22-50V
-
Maximum DC short current: 40A
-
Recommend the use of PV modules: 2*300W/Vmp>34V/Voc<50V
-
Maximum input current: 25A
* 【Waterproof】- IP65 waterproof class, effectively prevent rainwater from eroding the surface. Connected in parallel, minimizing safety hazards. High quality and safe enough
* 【MPPT Function】- High performance powerful MPPT (maximum power point tracking) algorithm, optimize the power from the solar panels to collect. Capture and collect sunlight effectively.
* 【Reverse Power Transmission】- Adopts reverse efficient power transmission technology. Extra electricity is transmitted to the grid. Efficient use of the inverter to the power emitted.
* 【Intelligent Monitoring】- The inverter can collect real-time data with intelligent monitoring system, can be controlled start-up / shutdown / power regulation
* 【User Serviceable】- Parallel installation, the micro inverter can be installed directly at a later stage without changing the previous configuration. It is simple whether installation or maintenance
